| Dimension | (H)96mm x (W)96mm x (D)54mm |
| Supply Voltage | 100-270V AC |
| Input | Proximity or Micro Switch Input |
| Display | 4-Digit Dual Display with Set RPM & Present RPM |
| Country of Origin | Made in India |
- Proximity or Micro Switch Input
- 4-Digit Dual Display with Set RPM & Present RPM
- Upto 2-Relay Output
- Size: (H)96mm x (W)96mm x (D)54mm
- Supply Voltage: 100-270V AC
| Display | UPPER:- 4-Digit, 7-Seg 0.70”,red LED Display LOWER:- 4-Digit 7-Seg 0.4”,green LED Display |
||
| Size (mm) | 96 (H) X 96 (W) X 54 (D) | ||
| Panel Cutout (mm) | 92 (H) X 92 (W) | ||
| Input | NPN/PNP Proximity | ||
| Output | 1-Relay, 2-C/O Contact, 230V AC, 5A | ||
| Power Supply | 100 to 270V AC, 50/60 Hz, Approx 3VA | ||
| Operating Temperature | 0°C To 55°C | ||
| Relative Humidity | Upto 95% RH Non Condensing | ||
| Protection Level | IP-65 (Front side) As per IS/IEC 60529 : 2001 | ||
