| Control Type | On/Off |
| Output | 2Relay 1C/O (On-Off) |
| Range | Humidity (0.0 TO 100.0 % RH) |
| Protection Level | IP-65 (Front side) As per IS/IEC 60529 : 2001 |
| Country of Origin | Made in India |
- Humidity Sensor Input
- 2-Relay Output for Humidification/Dehumidification Function
- RS-485 Modbus
- Analog Retransmission output.
- Size: (H)96mm x (W)96mm x (D)54mm
- Supply Voltage: 100-270V AC
| Display | Upper display, 7-Seg, Red 0.56” LED for Process Value |
| Lower display, 7-Seg, White 0.56” LED for Process Set Value | |
| Dimension | Size (mm): 96(H) X 96(W) X 54(D) |
| Panel Cutout | 92 (H) X 92 (W) |
| Input | RH-100 ( Humidity) |
| Range | Humidity (0.0 TO 100.0 % RH) |
| Supply | 100 To 270V AC, 50/60 Hz, Approx 4VA |
| Output | 2Relay 1C/O (On-Off) |
| Protection Level | IP-65 (Front side) As per IS/IEC 60529 : 2001 |
