| Valve Size | 0.25 inch |
| Media | Air |
| End Connection Type | Flanged |
| Automation Grade | Semi Automatic |
| Material | SS ASTM A351 Grade CF8 / CF8M, Forged Brass |
| Maximum Pressure | 10bar |
| Application | Food Industries, Pharmaceuticals, Chemical application & Highly corrosive environment. |
| Operating Voltage & Power Consumption : | 24AC/9W, 110AC/9W, 230AC/9W, 12DC/10W, 24DC/11W |
- Port : 3/8″ -2″ 0-10bar (Available BSP / NPT)
- End Connection : Screwed / Flange
- Body Material : SS ASTM A351 Grade CF8 / CF8M, Forged Brass
- Circumstance Temp : -10°C to 70°C
- Media : Air, Water, Chemical, Gas, Oil, Steam, LPG.
Main Features :
- Internal Parts are in superior corrosion resistance steel, (Equivalent to SS316L)
- Suitable for Food Industries, Pharmaceuticals, Chemical application & Highly corrosive environment.
